PROCON-Connect

PROCON-Connect - Simple acquisition, pre-processing and communication of data

PROCON-Connect enables a wide range of data- and service-orientated industrial IoT use cases. The connections to controllers, databases and the interfaces to other software solutions are conveniently configured in the browser.

n addition to the extensive driver portfolio for connecting controllers, PROCON-Connect relies on industry-compatible standards (e.g. InfluxDB) and makes it possible to use the machine and energy data in Weidmüller solutions ResMa® and easyConnect, among others, or to send it directly to other cloud solutions via MQTT.

Your advantages

Platform independent App

Simple installation under u-OS using the App Manager and on any hardware
using Docker containers

Open standards and interfaces

Communication drivers, database technologies, APIs and cloud interfaces of PROCON-Connect are based on open standards (e.g. OPC-UA, InfluxDB or MQTT) and, in addition to our APIs, allow seamless integration into the IIoT infrastructure.

Intuitive web engineering

PROCON-Connect can be completely parameterised in the browser at runtime. In addition to the intuitive UI, extensive project management functions, such as the import and export of created projects, support you in the realisation of your applications.

Collect and utilise power and machine data intelligently with PROCON-Connect

PROCON-Connect enables the acquisition of energy and machine data from different controllers, energy meters and OPC-UA servers, for example. The data collected in this way can then be pre-processed directly in the app and stored in databases such as InfluxDB, for example. In addition, the data can be sent to the cloud via MQTT or used in ResMa® in the context of energy management.

Driver with browsing functionality: OPC-UA, ModbusTCP/RTU, CODESYS®, AllenBradley and driver for u-mation PLC
Installation via u-OS App Manager or on industrial PCs via Docker Container
Parameterisation of control connections, databases and cloud connections via browser

Data acquisition and data pre-processing with PROCON-Connect.

PROCON-Connect is the right start for the easy way into the Industrial IoT! The biggest advantage of the package is that it prepares you better for the future through flexibility and openness.

Efficient use of IT resources, since less than 20 MB of storage space is required
Central management of all apps on the gateway
Flexible use and stable process environment through Docker Container, and elimination of the need to start your own operating system
Convenient and easy-to-use web interface for project planning
Comprehensive range of open communication standards allows the user to link to many commonly used control systems and OPC-UA energy meters

Overview of PROCON-Connect components

PROCON-Connect offers a comprehensive platform for the efficient collection, processing and visualisation of machine and energy data. The solution has a modular structure and covers all relevant tasks – from system coordination and data communication to secure storage and cloud connectivity.

System Management

Central infrastructure components for coordinating all apps on the gateway.

Process Communication

Configuration of the communication drivers and management of the variables.

Data Logger

Storage and visualization of historic values as charts.

Cloud Gateway & Connector

Onboarding in the cloud and configuration of the individual connections.

Condition monitoring made easy with PROCON-Connect

With PROCON-Connect, you can implement condition monitoring solutions flexibly and future-proof – both in new (greenfield) and existing (brownfield) applications. Thanks to a wide range of integrated communication drivers, you have quick access to all relevant machine data such as temperature, vibration, current consumption or pressure.

The recorded data can be reliably stored in databases and is thus available for detailed analyses and long-term evaluations. Alternatively, machine data can be transferred securely and efficiently in cloud environments using standardised protocols such as MQTT. This paves the way for higher-level applications such as predictive maintenance, data visualisation and AI-supported optimisations.

PROCON-Connect makes it easy for you to gain transparency about the status of your machines, detect failures at an early stage, and increase the efficiency of your production in a sustainable manner.

MQTT – The smart communication solution for your machines

In modern industry, fast, secure and flexible data communication is the key to success. This is precisely where MQTT (Message Queuing Telemetry Transport) comes in: a lightweight protocol designed specifically to enable data exchange with reliability between machines, systems and cloud applications.

Efficient & resource-saving – ideal for systems with limited bandwidth.

Secure – MQTT communication complies with the latest security standards

Scalable – whether you have a few pieces of equipment or thousands of sensors, MQTT grows with your requirements.

Flexible application – perfect for Industry 4.0, IIoT applications and networked HMI systems.

Your advantage with PROCON-WEB & MQTT

With PROCON-WEB, you can seamlessly integrate MQTT into your automation solutions. This allows you to create transparent data flows, easily integrate cloud services, and make your production fit for the future.

Experience how easy modern communication can be.

More than software

We not only offer solutions for capturing, processing and analysing data in industrial applications, but also a comprehensive engineering service to meet your individual requirements. With our solutions, you can benefit from improved transparency and efficiency in your processes.

IIoT Software

IIoT software offers a comprehensive solution of data acquisition, data pre-processing and data visualisation in industrial applications.

Consulting

Consulting and planning for your individual software solution

Use cases

Our software solutions for your industry

Consulting & Support

We at Weidmüller GTI Software are pioneers in the field of software development. More questions? Then our competent team is always at your side. We support you in finding the right solution for your individual situation.
